Self Loading Mixer Machine

Get a Price/Quote

MOQ : 1 Unit

Self Loading Mixer Machine Specification

Surface
Powder Coated

Lifting Height
4.2 meters

Motor Power
76 HP Diesel Engine

Lifting Speed
16 m/min

Product Type
Self Loading Mixer Machine

General Use
Construction Concrete Mixing

Material
Heavy-Duty Steel

Type
Automatic Mixer

Capacity
1.2 Cubic Meter per batch

Weight (kg)
3200 kg

Computerized
No

Automatic
Yes

Cooling System
Water Cooled

Method
Self Loading and Mixing

Voltage
24V (DC for Controls)

Dimension (L*W*H)
6700 x 2300 x 3000 mm

Feature
360 Degree Drum Rotation

Color
Yellow

Max Output Volume/Hour
7~8 Cubic Meters

Chassis
High-Tensile Rigid Frame

Tyre Type
Heavy-duty Off-road Tyres

Steering Type
Power Steering

Discharge System
Hydraulic Operated

Fuel Tank Capacity
70 Liters

Water Tank Capacity
350 Liters

Driver Cabin
Roofed, Single Operator

Mixing Blade
Integrated Spiral Design

Drum Rotation Speed
13-16 rpm

Self Loading Mixer Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
15 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Self Loading Mixer Machine

PARAMETER	SLM 2200	SLM2200(T2.3)	SLM 2800	SLM 4300
ENGINE	49.5 hp 2200rpm	49.5 hp 2200rpm	74.5 hp 2200rpm	110 hp 2200rpm
DRUM OUTPUT	2.2 M3	2.3 M3	2.8 M3	4.3 M3
DRUM ROTATION	0 to 22 Rpm	0 to 22 Rpm	0 to 21 Rpm	0 to 21 Rpm
WATER TANK	580 Lit	580 Lit	600 Lit	800 Lit
FUEL TANK	80 Lit	80 Lit	100 Lit	110 Lit
BUCKET CAPACITY	500 Lit	500 Lit	550 Lit	650 Lit
WATER PUMP CAPACITY	275 Lpm	275 Lpm	275 Lpm	275 Lpm
VEHICLE SPEED	0-23 Kmph	0-23 Kmph	0-25 Kmph	0-29 Kmph
GRADEABILITY	23o	23o	25o	22o
UNLADEN WEIGHT	6300 Kg	6560 Kg	7450	8450 Kg
TYRE	12.5-18MT63 16PR HD	12.5-18MT63 16PR HD	12.5-18MT63 16PR HD	405-70-20 MT54 14PR HD
DRIVE	4 Wheel Drive	4 Wheel Drive	4 Wheel Drive	4 Wheel Drive
VARIANT	Swivel	Non-Swivel	Swivel / Non-Swivel	Swivel / Non-Swivel

Unlock the premier advancements in construction efficiency with our Self Loading Mixer Machine-engineered for triumphant results. For a limited time, shop now to experience the marvelous synergy of high performance and operator convenience. With a robust 76 HP diesel engine, an integrated spiral mixing blade, and a 1.2 cubic meter batch capacity, this automatic mixer is designed for heavy-duty applications. Boasting a 360-degree drum rotation, hydraulic discharge system, and rigid high-tensile chassis, it provides unparalleled reliability. Don't miss this opportunity to elevate your project outcomes!

Applications & Extra Features of the Self Loading Mixer Machine

The Self Loading Mixer Machine is masterfully used for mixing concrete in construction projects, excelling on rugged, off-road surfaces. It features a 350-liter water tank, heavy-duty steel build, and integrated spiral mixing blade. With automatic operation, 360-degree drum rotation, and a powerful hydraulic system, this marvel guarantees superior mixing results and efficient discharge. Whether on urban construction sites or remote developments, its robust structure and high-tensile frame ensure consistent performance on any surface.

Dispatching, Delivery Times & Certifications of the Mixer

Valuation and market value of our Self Loading Mixer Machine remain unmatched due to its reliability and efficiency. Expect swift dispatching, with typical delivery times adjusted to the client's location in India. Sample units are available upon request, assisting you with thorough evaluation before purchase. Our machines come thoroughly certified for quality and safety, assuring you peace of mind and compliance for any construction environment. Shop now to secure certified performance and prompt, reliable delivery.

FAQ's of Self Loading Mixer Machine:

Q: How does the self-loading and mixing process work in this mixer?

A: The mixer automatically loads materials into the drum using its integrated system. As the drum rotates 360 degrees, the spiral mixing blades blend the contents evenly. The hydraulic-operated discharge system allows for efficient and controlled pouring.

Q: What are the main benefits of using a self loading mixer machine for construction?

A: This machine significantly reduces labor needs, speeds up concrete production, and ensures consistent mixing quality. Its mobility and off-road tyres allow it to operate in varied terrains, making construction work more efficient and cost-effective.

Q: Where can this marvelously engineered mixer be used?

A: It is ideal for use in building construction, roadworks, and infrastructure projects, especially where reliable concrete mixing is required in remote or challenging environments.

Q: When can I expect delivery after placing an order?

A: Delivery times are typically finalized based on the client's location and current market demand; dispatching is prompt to ensure you receive your mixer as soon as possible.

Q: What certifications does the Self Loading Mixer Machine hold?

A: Each mixer unit is certified for safety, quality, and performance, providing assurance of compliance with industry standards required for construction machinery in India.

Q: How does the hydraulic control system enhance the machine's operation?

A: The hydraulic system powers both the discharge and mixing operations, making loading, mixing, and pouring more precise and less labor-intensive, enhancing operational efficiency.
